Electrical Specifications | |
Cable Impedance | 50 ohm ±1 ohm |
Capacitance | 25.2 pF/ft | 82.7 pF/m |
dc Resistance, Inner Conductor | 0.820 ohms/kft | 2.690 ohms/km |
dc Resistance, Outer Conductor | 1.560 ohms/kft | 5.120 ohms/km |
dc Test Voltage | 2500 V |
Inductance | 0.207 µH/m | 0.063 µH/ft |
Insulation Resistance | 100000 Mohms•km |
Jacket Spark Test Voltage (rms) | 5000 V |
Operating Frequency Band | 1 – 10200 MHz |
Peak Power | 22.5 kW |
Velocity Precio por pie | 81%
|
