AVA5-50FX - AVA5-50FX-ANDREW / COMMSCOPE-Cable coaxial HELIAX 7/8", cobre corrugado, blindado, 50 Ohms - Relematic.mx - AVA550FX-p

Thumbnail

AVA5-50FX-ANDREW / COMMSCOPE-Cable coaxial HELIAX 7/8″, cobre corrugado, blindado, 50 Ohms

ANDREW / COMMSCOPE

SKU: AVA5-50FX Categorías: Cables, Coaxiales, Radiocomunicación Brand: ANDREW / COMMSCOPE

$330.89 MXN IVA incluido+$99.49 MXN de envio

Agotado

¡Envíos en tiempo récord!

Paga rápido y seguro

Descripción

Especificaciones eléctricas:

Impedancia: 50 Ω.
Diámetro Exterior: 28 mm.
Factor de Velocidad: 91 %.
Atenuación en 30 mts UHF 450 MHz: 0.73 dB.
Atenuación en 30 mts UHF 800 MHz: 0.99 dB.
Diámetro Conductor Interno (mm): 9.45.
Aislamiento: Espuma Dieléctrica de baja densidad.
Blindaje: Cobre corrugado sólido 100 %.
Peso por Metro (Kg): 0.45

*PRECIO POR METRO*

Diferencias contra el AVA5-50

Conector central solido

Resistencia conector central 2.888 ohms/km | 0.88 ohms/kft

Resistencia conector exterior 1.53 ohms/km | 0.466 ohms/kft

Velocidad 90 %

Temperatura de operación -55 °C to +70 °C (-67 °F to +158 °F)

Temperatura de almacenaje -70 °C to +70 °C (-94 °F to +158 °F)

Peso 0.41 kg/m | 0.276 lb/ft

Información adicional

Peso	0.45 kg

Hoja técnica
